Industry Construction Building Portal Frame Structural Steel Frame Workshop
Structural Design: The portal frame is a structural system that consists of rigid frames with columns and rafters connected by high-strength bolts or welds. It provides stability and strength to the building. The design should consider the size and spacing of the frames, the height and span of the building, and the expected loads and forces that the structure will experience.
Space Planning: Efficient space planning is critical for workshop buildings. Consider the workflow, equipment layout, and storage requirements. Determine the optimal arrangement of work areas, machinery, assembly lines, and storage spaces to facilitate smooth operations and maximize productivity.
Clear Span Design: Portal frames are often designed to provide clear spans, which means there are no interior columns that obstruct the open floor space. This allows for flexible use of the interior space and easy movement of machinery and equipment. Consider the required clear span width based on the specific needs of the workshop.
Roofing and Cladding: Select appropriate roofing and cladding materials that provide weather protection and insulation. Metal roofing and cladding systems are commonly used in steel frame workshops due to their durability, low maintenance, and ease of installation. Consider insulation options to regulate temperature and reduce energy costs.
Natural Lighting and Ventilation: Incorporate natural lighting features such as skylights and windows to reduce the reliance on artificial lighting during the day. Adequate ventilation is crucial to maintain a comfortable and healthy working environment. Design the structure to include vents, louvers, or mechanical ventilation systems as needed.
Electrical and Plumbing Systems: Plan for the installation of electrical systems, including lighting, power outlets, and machinery connections. Consider the specific power requirements of the workshop equipment and ensure sufficient capacity to support the operations. Similarly, design the plumbing systems to accommodate water supply, drainage, and any specific needs such as washrooms or specialized processes.
Fire Safety Measures: Implement appropriate fire safety measures, including fire-rated materials, fire suppression systems, and clearly marked fire exits. Ensure compliance with local fire codes and regulations to prioritize the safety of workers and protect the facility.
Foundation and Site Preparation: The design should consider the foundation requirements based on the soil condition and load-bearing capacity of the site. Engage geotechnical experts to conduct soil tests and provide recommendations for the foundation design. Prepare the site by clearing any obstacles and ensuring proper grading.
Product Parametes
|
Steel structure building
|
|
1. Primary Framing
|
Painted or hot-galvanized H column and beam
|
|
2. Secondary Framing
|
Galvanized Z and C sections purlin
|
|
3. Roof and Wall panels
|
Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU)
|
|
4. Steel Decking Floor
|
Galvanized steel decking board
|
|
5.Structural subsystem
|
Canopies, fascias, partitions, etc.
|
|
6.Mezzanines, Platforms
|
Painted or galvanized H beam
|
|
7.Other Building Accessories
|
Sliding doors, roll up doors, aluminium windows, louvers, etc.
|
|
Drawings & Quotation:
|
|
(1) Customized design is welcomed.
|
|
(2) In order to provise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.
We will quote for you promptly.
|
Company Profile
Shandong Juxin Steel Structure Co., Ltd. is specialized in building steel structure design, manufacturing, installation, maintenance as one of the professional enterprises. Integrated design, manufacturing, installation in one, with H-shaped steel; C, Z steel; Bolt ball joint grid; Color light roof panel, wall panel; office integrated activity room and other production lines, has its own professional design office, professional processing equipment, professional testing equipment, professional quality inspection personnel, professional manufacturing base, professional production and technical personnel, professional installation team and perfect operation, after-sales service team.
Product Description
Our advantage
Certifications
Customer Case
We will consider the standards and specifications of each region. Therefore, by choosing us, you will obtain steel structure products that fully comply with the legislative requirements of your country/region. At the same time, we have many experiences in industrial buildings, public buildings, bridge buildings, marine engineering, livestock building, high-rise buildings, aerospace, military construction, and other fields.
We will carefully study your specific needs and specifically design and manufacture load-bearing structures suitable for your project.
FAQ
Q1: How long does it take to get my building?
A: Lead time is vary, but typically 2 weeks of drawings and 6-8 weeks for delivery(depending on complexity)
Q2: What are the benefits of steel construction?
A: 1-Durable and with long lifespan.
2-Short construction period than concrete and wooden building.
3-Low cost and reusable.
4-High strength and light weight, has good seismic performance.
5-Widely used for multi-purpose buildings.
Q3: Why choose JU XIN?
A: At JU XIN, the customer is the first priority. We don't pull any gimmicks. We are veteran owned and operated business, unmatched in customer service. We have more than 20 years of metal building experience. We are also very reputable manufacture and can answer your questions regarding any tape of construction project.We care about your needs and value your business.
Q4: How can l get the quotation of the project?
A: lf you have the drawing, we can offer you our quotation accordingly. lf youhave no design, our engineer will design for you to confirm. And then offer you a quotation.
Q5: Do you offer designing service for us?
A: Yes, we can provide full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (X steel) and etc. We can design complex industrial building like office building,
supermarket, auto dealer shop, shipping mall, hotel etc.
Q6: Do you provide samples?
A: Yes, we could offer the sample for free but do not pay for the cost of transportation.
Q7: What is your terms of payment ?
A: L/C, T/T, and Western Union.
Q8: How about your quality control?
A: We have our own professional quality control team with rich experience and advanced inspection equipment. Also we are willing to accept any other the third inspection part to control.
Q9: Can you provide the installation help?
A: We will provide detailed instruction photos and videos to you. If it is necessary,we will send professional engineers to do the construction guidance, and some skilled workers to help for installation. However, the visa fee, air tickets,accommodation, wages will be provided by buyers.
