Common Types of Steel Structures--Workshop Warehouse Factory Building
Steel structures are widely used in workshop, warehouse, and factory buildings due to their strength, durability, and versatility. Here are some common types of steel structures utilized in these applications:
-
Rigid Frame Structures: Also known as clear span structures, they consist of steel columns and beams connected by rigid joints to create expansive column-free interiors. Ideal for workshops and warehouses where large, uninterrupted floor space is required, such as manufacturing plants or aircraft hangars.
-
Portal Frame Structures: This type uses a 'portal' configuration with horizontal beam (rafter) spanning between two vertical columns. The top and bottom chords of the portal frame are connected by web members, creating a truss-like system. Commonly seen in smaller to medium-sized warehouses and factories.
-
Multi-Story Steel Frames: For larger factory buildings that require office spaces, laboratories, or multi-level production lines, multi-story steel structures are employed. These can be either moment-resisting frames or braced frames, providing stability against lateral forces like wind and earthquakes.
-
Long-Span Truss Systems: In very large workshops or warehouses, long-span trusses are used to cover great distances without intermediate supports. These complex assemblies distribute loads effectively over their length, allowing for maximum utilization of the floor area below.
-
Composite Steel Deck Floors: Combining steel deck with concrete creates a composite floor system that is both lightweight and strong, commonly found in mezzanine levels or elevated work platforms in factories.
-
Prefab Modular Steel Buildings: Components are pre-engineered and fabricated offsite, then assembled on location. This method speeds up construction time and reduces costs, making it popular for warehouses and workshops where quick occupancy is essential.
-
Cold-Formed Steel Structures: Thin-gauge sheet steel is roll-formed into C-sections, Z-sections, or other shapes for framing lighter-duty structures such as small workshops, agricultural buildings, or extensions to existing structures.
-
Lattice Girder or Tubular Structures: Used for exceptionally large spans or heavy loads, these structures are characterized by interconnected tubular sections or lattice girders, often seen in heavy industrial settings or large mining warehouses.
Each type of steel structure is chosen based on the specific needs of the project, including the size, intended use, local climate conditions, seismic considerations, and budget constraints.
Product Parametes
|
Steel structure building
|
|
1. Primary Framing
|
Painted or hot-galvanized H column and beam
|
|
2. Secondary Framing
|
Galvanized Z and C sections purlin
|
|
3. Roof and Wall panels
|
Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU)
|
|
4. Steel Decking Floor
|
Galvanized steel decking board
|
|
5.Structural subsystem
|
Canopies, fascias, partitions, etc.
|
|
6.Mezzanines, Platforms
|
Painted or galvanized H beam
|
|
7.Other Building Accessories
|
Sliding doors, roll up doors, aluminium windows, louvers, etc.
|
|
Drawings & Quotation:
|
|
(1) Customized design is welcomed.
|
|
(2) In order to provise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.
We will quote for you promptly.
|
Company Profile
Shandong Juxin Steel Structure Co., Ltd. is specialized in building steel structure design, manufacturing, installation, maintenance as one of the professional enterprises. Integrated design, manufacturing, installation in one, with H-shaped steel; C, Z steel; Bolt ball joint grid; Color light roof panel, wall panel; office integrated activity room and other production lines, has its own professional design office, professional processing equipment, professional testing equipment, professional quality inspection personnel, professional manufacturing base, professional production and technical personnel, professional installation team and perfect operation, after-sales service team.
Product Description
Our advantage
Certifications
Customer Case
We will consider the standards and specifications of each region. Therefore, by choosing us, you will obtain steel structure products that fully comply with the legislative requirements of your country/region. At the same time, we have many experiences in industrial buildings, public buildings, bridge buildings, marine engineering, livestock building, high-rise buildings, aerospace, military construction, and other fields.
We will carefully study your specific needs and specifically design and manufacture load-bearing structures suitable for your project.
FAQ
Q1: How long does it take to get my building?
A: Lead time is vary, but typically 2 weeks of drawings and 6-8 weeks for delivery(depending on complexity)
Q2: What are the benefits of steel construction?
A: 1-Durable and with long lifespan.
2-Short construction period than concrete and wooden building.
3-Low cost and reusable.
4-High strength and light weight, has good seismic performance.
5-Widely used for multi-purpose buildings.
Q3: Why choose JU XIN?
A: At JU XIN, the customer is the first priority. We don't pull any gimmicks. We are veteran owned and operated business, unmatched in customer service. We have more than 20 years of metal building experience. We are also very reputable manufacture and can answer your questions regarding any tape of construction project.We care about your needs and value your business.
Q4: How can l get the quotation of the project?
A: lf you have the drawing, we can offer you our quotation accordingly. lf youhave no design, our engineer will design for you to confirm. And then offer you a quotation.
Q5: Do you offer designing service for us?
A: Yes, we can provide full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (X steel) and etc. We can design complex industrial building like office building,
supermarket, auto dealer shop, shipping mall, hotel etc.
Q6: Do you provide samples?
A: Yes, we could offer the sample for free but do not pay for the cost of transportation.
Q7: What is your terms of payment ?
A: L/C, T/T, and Western Union.
Q8: How about your quality control?
A: We have our own professional quality control team with rich experience and advanced inspection equipment. Also we are willing to accept any other the third inspection part to control.
Q9: Can you provide the installation help?
A: We will provide detailed instruction photos and videos to you. If it is necessary,we will send professional engineers to do the construction guidance, and some skilled workers to help for installation. However, the visa fee, air tickets,accommodation, wages will be provided by buyers.
