Product Discription
Steel structure building is a new type of building structure system for production,which is formed by the main steel framework linking up H section,Z section and U section steel components,travelling crane,roof and walls using a variety of panels and other components such as windows, doors,cranes,etc.
It can be widely used for workshop, warehouse, garage,garden storage shed, airpaort,office building,apartment,and all kinds of steel buildings, metal buildings, modular house, steel frame for other riveting and welding parts etc.
The sizes can be customized according to requirement.
Key Attributes
Type
prefabricated steel warehouse
After-sale Service
Online technical support, Onsite Installation, Onsite Training
Project Solution Capability
graphic design, 3D model design, total solution for projects
| Main Materials for Steel Structure Consturction |
| Item |
Materials |
Remark |
Steel
Frame |
H section column and beam |
Q345 steel, paint or galvanization |
| wind resistant column |
Q345 steel, paint or galvanization |
Secondary bracing |
Roof purlin |
Q235B C/Z section galvanized steel |
| Wall purlin |
Q235B C/Z section galvanized steel |
| Tie bar |
Q235,φ89*3 round steel pipe |
| knee brace |
angle steel,Q235,L50*4 |
| roof horizontal bracing |
φ20,Q235B steel bar, paint or galvanized |
| column vertical bracing |
φ20,Q235B steel bar, paint or galvanized |
| casing pipe |
φ32*2.0,Q235 steel pipe |
| Pulling bar |
Φ10 round bar Q235 |
Roof and wall
protecting system |
Wall and roof panel |
corrugated steel sheet/sandwich panel |
| gutter |
color steel sheet/galvanized steel/stainless steel |
| Trim and flashing |
color steel sheet |
| downspout |
PVC |
| self tapping screw |
|
Fastener system |
Anchor bolts |
Q235 steel |
| High strength bolt |
The Specifications shall be determined according to the design of steel structure. |
| Normal bolt |
|
| Nuts |
|
| Window and door |
Window |
Aluminium windows |
| Door |
According to requirement to choose, can be EPS door, windproof door, high-speed roll-up door, industrial sliding door etc. |
Company Profile
Juxin Group established for over 30 years, we have built strong technical backgrond team,advanced machinery & equipment,standard management system,perfect after-sale service we we have gathered rich experience on design, production, installation, we have production an ability of mass order, Whatever your need we will try our ulmost to meet your requiremt.
1. High quality, strong, durable and stable, fashionable.
2. Modularization-specific design ability
3. Fast and easy erection and installation
4. Cheaper, lower maintenance cost than any other construction method
5. Good waterproof and flameproof
6. Longer life than other identical products
7. Environmentally friendly, steel and components can be recyled without effecting the environment
8. Uniform quality
9. Economy in transportation and handling
10. After sales: professional installation team.
11. Can provide integrated engineering
Product Description
Shandong Juxin Steel Structure Co., Ltd. is specialized in building steel structure design, manufacturing, installation, maintenance as one of the professional enterprises. Integrated design, manufacturing, installation in one, with H-shaped steel; C, Z steel; Bolt ball joint grid; Color light roof panel, wall panel; office integrated activity room and other production lines, has its own professional design office, professional processing equipment, professional testing equipment, professional quality inspection personnel, professional manufacturing base, professional production and technical personnel, professional installation team and perfect operation, after-sales service team.
Our main scope:
1. Steel Construct Multi & super high rise building(CBD Building).
2. Steel Construct Public buildings
3. Steel Construct Bridge
4. Steel Construct Workshop, Wareshouse, Farm
5. Steel Construct Residential Living Community.
6. Steel Construct Airport, Train Station.
Our advantage
Certifications
Customer Case
FAQ
Q1: What are the main products your company produces?
A: The business scope of my company is mainly structural steel construction, such as industrial building, commercials building, prefab house, etc. In addition, we also provide steel structure processing service, like the processing of H- steel, steel beam, color steel plate, C-Purlin steel, Z-Purlin steel , floor deck etc.
Q2: What are the benefits of steel construction?
A: 1-Durable and with long lifespan.
2-Short construction period than concrete and wooden building. 3-Low cost and reusable.
4-High strength and light weight, has good seismic performance.
5-Widely used for multi-purpose buildings.
Q3: What drawings will you supply?
A: Plan drawing, elevation drawing, sectional drawing, foundation drawing, construction drawing and installation drawing.
Q4: What is your terms of payment?
A: L/C and T/T
